Round bar 6-40mm
Deformed bar 6-28mm
Bending speed 20-30pcs/min
Motor power 3kw-4P/1440rpm
Input voltage 220v/380v/415v
Working mode Gearbox/Worm gear
Panel thickness 5mm
Disk diameter 340*38mm
Disk block 455*72*47mm
Net Weight 222kg
Gross Weight 242kg
Dimension 850*790*770mm
| Model | GW40 |
| Bending range
(mm) |
Round bar： 6-40mm Deformed bar ：6-28mm |
| Bending speed | 20-30pcs/min |
| Motor power | 3kw-4P/1440rpm |
| Input voltage | 220v/380v/415v |
| Working mode | Gearbox/Worm gear |
| Panel thickness | 5mm |
| Disk diameter | 340*38mm |
| Disk block | 455*72*47mm |
| Net Weight | 222kg |
| Gross Weight | 242kg |
| Dimension | 850*790*770mm |
Gaoteng Machinery’s service network spans the globe, and our team is always ready to provide timely and efficient pre-sales consultation and after-sales support, ensuring you have the best experience when using our products.
