WEIGHT
|
|
Max. Operate weight
|
530KGS
|
No-load weight
|
260KGS
|
DIMENSION
|
|
Max. length
|
2000MM
|
Whole dimension
|
1690*1000*1150MM
|
Max. working width
|
1000MM
|
Min. working width
|
250MM
|
BASE
|
|
Front drive wheel
|
2*Hydraulic drive wheel, diameter 400mm
|
Rear steering wheel
|
1*Universal wheel, diameter 260mm
|
SPEED
|
|
Max. working speed
|
28M/MIN
|
Max. transition speed
|
3.2km/h
|
ENGINE
|
|
Model
|
HONDA GXV160
|
Emission standard
|
EPA
|
Rated power
|
3.2KW
|
Configuration
|
Air-cooling, single-cylinder, petrol engine
|
Cylinder number
|
1
|
Fuel tank volume
|
4L
|
HOPPER
|
|
Hopper volume
|
150L
|
STANDARD CONFIGURATION
|
|
1) Hydraulic axle two-wheel drive, universal steering wheel
|
|
2) Forward and backward handle control
|
|
3) The left and right double oil cylinders independently control the paving thickness
|
|
4) 4 kinds of paving width options
|
|
5) Engine exhaust ironing board heating function
|
|
6) Detachable hopper
|
|
7) Lever brake
|
Pothole Patching: Say goodbye to those troublesome potholes that wreak havoc on roads. Our asphalt paver makes quick work of pothole repairs, restoring smooth driving surfaces.
Crack Filling: From subtle surface cracks to more substantial mesh cracks, our machine ensures effective and durable crack repair, preventing further deterioration.
Precise Repairs: Even the smallest of imperfections receive the attention they deserve, leaving no area untouched, no matter how minor the damage may seem.
Recycling Asphalt Mix: Not only does our asphalt paver mend the pavement, but it’s also capable of heating and mixing waste asphalt mixture, making it an eco-friendly choice for recycling and reusing materials.
Efficient and Reliable: With the efficiency to handle both common issues and recycling, our asphalt paver streamlines the repair process, saving you time and resources.
Versatile Applications: Whether you’re maintaining roads, driveways, parking lots, or other asphalt surfaces, our paver is the solution you can rely on.
Built to Last: Our asphalt paver is engineered to withstand demanding tasks and provide long-lasting performance, ensuring a dependable partner in your pavement maintenance efforts.
