Power：1.5KW
Rotational Speed: 1440R/MIN
Frequency：50/60Hz/s
I-beam：75-125MM
Lifting Height: 3M
Lifting Speed: 6.8M/MIN
Capacity: 1Ton
Brand Name：GaoTeng Machine
| Model HSY | Capacity
(ton) |
Lifting Height
(m) |
Lifting Speed
(m/min) |
Lifting motor | I-beam
(mm) |
||||
| Power
KW |
Rotational Speed
(r/min) |
Phase | Voltage
(V) |
Frequency
(Hz/s) |
|||||
| 1-1 | 1 | 3 | 6.8 | 1.5 | 1440 | 3 | 380/220 | 50/60 | 75-125 |
| 2-2 | 2 | 3 | 3.4 | 1.5 | 1440 | 3 | 380/220 | 50/60 | 75-125 |
| 2.5-1 | 2.5 | 3 | 5.6 | 3.0 | 1440 | 3 | 380/220 | 50/60 | 82-153 |
| 3-2 | 3 | 3 | 3.3 | 3.0 | 1440 | 3 | 380/220 | 50/60 | 82-153 |
| 5-2 | 5 | 3 | 2.8 | 3.0 | 1440 | 3 | 380/220 | 50/60 | 100-178 |
